Welcome to our product introduction page. We are a leading manufacturer of high-quality stranded copper wire in China. Our company has been in the business for many years, and we have built a reputation for delivering products of the highest quality. Our stranded copper wire is one of our flagship products that is sought-after not only in China but also in many countries outside of China.
Our copper wire has been designed to meet the needs of merchants that require high-quality wire for various applications. We understand that quality is essential, and that is why we have invested a lot of resources in ensuring that our product meets the highest standards. Our stranded copper is made from pure copper, which means that it is a material that is known for delivering excellent conductivity, is corrosion-resistant, and can also withstand high temperatures.
1. High Conductivity: Our stranded copper wire has been designed to deliver high conductivity. Thanks to the high-quality copper that we use, the wire can effectively transfer electricity without losing energy. This makes our product ideal for use in various applications that require high-efficiency wiring.
2. Excellent Corrosion Resistance: Corrosion can significantly compromise the integrity of wires, leading to electrical faults or even failures. Our stranded copper wire comes with excellent corrosion resistance properties that ensure that the wire will remain durable even when exposed to harsh environmental conditions, making it an ideal option for use in outdoor applications.
3. Heat Resistance: Our copper wire can withstand high temperatures without melting, deforming, or losing its electrical properties. It is an ideal material for use in applications like motors, transformers, and generators, where high-temperature environments are common.
4. Flexible and Easily Bendable: The flexibility and ease of use of our stranded copper wire are some of the reasons why merchants prefer our products. The wires are easily bendable and can be shaped into any desired form, making them ideal for use in various applications that require flexibility.
5. Low Maintenance: Our stranded copper wire is designed to be low maintenance. The wire is durable and can last for many years without requiring any significant maintenance. This makes it a cost-effective solution for merchants looking for reliable wiring materials.
Our stranded copper wire is incredibly versatile and can be used in various applications. Here are some of the common applications where our copper wire is widely used:
1. Electric Motors: Our wire is commonly used in electric motors due to its high conductivity and excellent heat resistance properties.
2. Transformers: Our copper wire can handle high-voltage applications, making it an ideal material for use in transformers.
3. Generator and Alternators: Our copper wire is perfect for use in generators and alternators due to its high performance in high-temperature environments. 4. Automotive: Our copper wire is also suitable for use in the automotive industry, where it is used in wiring harnesses that connect various systems in the vehicles.
5. Electronic Devices: Our stranded copper wire is perfect for use in various electronic devices, including smartphones, computers, and audio equipment, due to its high conductivity and ability to withstand high temperatures.
Our stranded copper wire is a reliable option for merchants looking for high-quality wiring materials. We are confident that our product will meet your needs and exceed your expectations. Our commitment to quality and exceptional customer service makes us the ideal partner for your business needs. Feel free to contact us for more information on how we can help you with your wiring needs.
Material: annealed Cu-ETP wires, C11000, copper content ≥ 99.95%
Finish: bare, tin plating, nickel plating, silver plating
Single Wire Diameter:
0.04mm
0.05mm (AWG 44)
0.07mm (AWG 41)
0.10mm (AWG 38)
0.12mm
......
Packing Modes: in rolls, on spools or wooden drums
1.The flexible copper stranded wire is made of high quality round copper wire or tinned soft round copper wire. During the processing process, the product is soft, neat and beautiful.
2.The current resistance of the copper stranded cable (20℃) is not bigger than 0.0182 ω mm2/m. The current resistivity of tinned copper stranded wire (20℃) is not bigger than 0.0193 ω mm2/m.
TS,TSX
|
Nominal Cross Section (mm²) |
Calculated cross-sectional area (mm²) |
Construction |
Calculated Outside diameter (mm) |
DC resistance Ω/km ≤ |
Calculated weight Kg/km |
||
|
The number of total single wires |
No. of strands x No.of wires Nominal diameter of a single wire(mm） |
TS |
TSX |
||||
|
0.25 |
0.242 |
63 |
7 X 9/0.07 |
1.0 |
75.5 |
81.1 |
2.28 |
|
0.315 |
0.323 |
84 |
7 X 12/0.07 |
1.1 |
56.6 |
60.7 |
3.04 |
|
0.40 |
0.404 |
105 |
7 X 15/0.07 |
1.2 |
45.2 |
48.6 |
3.81 |
|
0.50 |
0.512 |
133 |
7 X 19/0.07 |
1.3 |
35.7 |
38.3 |
4.82 |
|
0.63 |
0.620 |
161 |
7 X 23/0.07 |
1.5 |
29.5 |
31.6 |
5.84 |
|
0.80 |
0.808 |
210 |
7 X 30/0.07 |
1.6 |
22.6 |
24.3 |
7.61 |
|
1.00 |
0.990 |
1 26 |
7 X 18/0.10 |
1.8 |
18.5 |
19.3 |
9.33 |
|
1.25 |
1.264 |
161 |
7x23/0.10 |
2.0 |
14.5 |
15.1 |
11.9 |
|
1.6 |
1.594 |
203 |
7x29/0.10 |
2.2 |
11.5 |
12.0 |
15.0 |
|
2.0 |
1.979 |
252 |
7x36/0.10 |
2.4 |
9.23 |
9.65 |
18.6 |
|
2.5 |
2.47 |
315 |
7x45/0.10 |
2.7 |
7.39 |
7.72 |
23.3 |
|
3.15 |
3.134 |
399 |
7x57/0.10 |
3.0 |
5.83 |
6.09 |
29.5 |
|
4.0 |
3.958 |
504 |
7x72/0.10 |
3.3 |
4.62 |
4.83 |
37.3 |
|
5.0 |
4.948 |
630 |
7x90/0.10 |
3.8 |
3.96 |
3.73 |
46.6 |
|
6.3 |
6.243 |
552 |
12x46/0.12 |
4.3 |
2.94 |
3.07 |
59.1 |
|
8 |
7.872 |
696 |
12X 58/0.12 |
4.8 |
2.33 |
2.44 |
74.5 |
|
10 |
10.04 |
888 |
12 X 74/0.12 |
5.3 |
1 .83 |
1.91 |
95.1 |
|
12.5 |
12.46 |
1102 |
19x 58/0.12 |
5.9 |
1 .48 |
1.55 |
118.5 |
|
16 |
15.90 |
1406 |
19x74/0.12 |
6.7 |
1 .16 |
1.21 |
151.2 |
|
Nominal Cross Section (mm²) |
Calculated cross-sectional area (mm²) |
Construction |
Calculated Outside diameter (mm) |
DC resistance |
Calculated weight Kg/km |
||
|
The number of total single wires |
Number of strands x No.of wires Nominal diameter of a single wire(mm) |
TS |
TSX |
||||
|
0.063 |
0.0628 |
32 |
32/0.05 |
0.5 |
288 |
0.586 |
|
|
0.08 |
0.0785 |
40 |
40/0.05 |
0.55 |
231 |
0.733 |
|
|
0.10 |
0.0982 |
50 |
50/0.05 |
0.6 |
184 |
0.917 |
|
|
0.125 |
0.124 |
63 |
63/0 05 |
0.65 |
146 |
1.16 |
|
|
0.16 |
0.165 |
84 |
7X12/0.05 |
0.7 |
111 |
1.55 |
|
|
0.20 |
0.206 |
105 |
7 X 15/0.05 |
0.8 |
88.7 |
1.92 |
|
|
0.25 |
0.247 |
126 |
7 X 18/0.05 |
1.0 |
74.0 |
2.33 |
|
|
0.315 |
0.316 |
160 |
7X 23/0.05 |
1.1 |
57.8 |
2.95 |
|
|
0.40 |
0.399 |
203 |
7 X 29/0.05 |
1.2 |
45.8 |
3.76 |
|
|
0.50 |
0.495 |
252 |
12 X 21/0.05 |
1.3 |
37.0 |
4.69 |
|
|
0.63 |
0.636 |
324 |
12 X 27/0.05 |
1.5 |
28.9 |
6.02 |
|
|
0.80 |
0.801 |
408 |
12 X 34/0.05 |
1.6 |
22.9 |
7.58 |
|
|
1.00 |
0.990 |
504 |
12 X 42/0.05 |
1.8 |
18.6 |
9.37 |
|
|
1.25 |
1.268 |
646 |
19 X 34/0.05 |
2.0 |
14.5 |
12.1 |
|
|
1.6 |
1.567 |
798 |
19 X 42/0.05 |
2.2 |
11.8 |
14.9 |
|
|
2.0 |
2.015 |
1026 |
19 X 54/0.05 |
2.4 |
9.16 |
19.2 |
|
|
2.5 |
2.500 |
1273 |
19x67/0.05 |
2.7 |
7.38 |
23.8 |
|
|
3.15 |
3.144 |
817 |
19 X 43/0.07 |
3.0 |
5.87 |
29.9 |
|
|
4.0 |
4.022 |
1045 |
19 X 55/0.07 |
3.3 |
4.59 |
38.3 |
|
|
5.0 |
1.927 |
1292 |
19 X 68/0.07 |
3.8 |
3.71 |
47.3 |
|
|
6.3 |
6.288 |
1634 |
19 X 86/0.07 |
4.3 |
2.93 |
59.8 |
|
Price: Our price fluctuates with raw materials and exchange rate. Please leave your contact information and we will give you a new quotation as soon as possible.
Flexible stranded wire is used for transmission and distribution of electrical devices (such as transformers, donkeys) and electrical equipment, silicon controlled components, and can also be used for electrical work grounding wire.
